Lexmark CS943de Color Laser Printer

Lexmark CS943de

Product Features

Features

• Color Laser
• Duplex (2-sided) Printing: Integrated Duplex
• Print Speed: Up to 55 ppm
• Recommended Monthly Page Volume: 7000 - 50000 pages
• 1-Year Onsite Repair, Next Business Day


Looking for Lexmark CS943 Parts?


Abstract

The Lexmark CS943de is a high-speed color laser printer designed for large workgroups of up to 50,000 monthly pages. Key features of this robust printer include print speeds of up to 55ppm in both black and color, built-in duplex printing, a 4.3" color touchscreen display, and standard connectivity options like Gigabit Ethernet, USB 2.0, and rear USB ports.

With a maximum monthly duty cycle of 270,000 pages, the CS943de can handle heavy daily use.

Its quad core 1.2GHz processor and 4GB of memory ensure fast performance. The printer supports media sizes from A6 to SRA3 and can hold 1,140 pages standard (expandable to 5,140). Toner cartridges yield up to 26,000 pages in color and 52,000 pages in black. Supported by Lexmark's 1-year onsite warranty, the CS943de brings fast, reliable color printing to busy workgroups.



Supplies

Lexmark CS943 Cyan 26K Toner Cartridge 73D0HC0 26,000	73D0HC0 Cyan Toner CS943DE New 73D0HC0 26,000 Page Yield (New) $691.99
Lexmark CS943 Magenta 26K Toner Cartridge 73D0HM0 26,000	73D0HM0 Magenta Toner CS943DE New 73D0HM0 26,000 Page Yield (New) $691.99
Lexmark CS943 Yellow 26K Toner Cartridge 73D0HY0 26,000	73D0HY0 Yellow Toner CS943DE New 73D0HY0 26,000 Page Yield (New) $691.99
Lexmark CS943 Black 52K Toner Cartridge 73D0HK0 52,000	73D0HK0 Black Toner CS943DE New 73D0HK0 52K Page Yield (New) $834.99
Lexmark 3-Pack 15K Finisher Staples 25A0013 15,000	25A0013 Staple Cartridges (3 pack) New 25A0013 (New) Contact for Details
Lexmark CS943, CX942, 943, 944, XC9445, 55, 65 35K Waste Container 73D0W00 35,000 1	73D0W00 CX942, 943, 944, XC9445, 55, 65 Waste Container New 73D0W00 35K Page Yield (New) $15.99
Lexmark CS943, CX942, 943, 944, XC9445, 55, 65 Black 165K Photoconductor 73D0P00 165,000 1	73D0P00 CX942, 943, 944, XC9445, 55, 65 Black Photoconductor New 73D0P00 165K Page Yield (New) $178.99
Lexmark CS943, CX942, 943, 944, XC9445, 55, 65 3-Pack 165K Photoconductor Kit 73D0Q00 165,000	73D0Q00 CX942, 943, 944, XC9445, 55, 65 3-Pack Photoconductor Kit New 73D0Q00 165K Page Yield (New) $505.99
2000-Sheet Tandem Tray - Letter	20L8803 20L8803 2000-Sheet Tandem Tray - Letter New 20L8803 (New) $1131.96 Exceeds UPS shipping dimensions / weight. Contact for Shipping Quote 20L8803 2000-Sheet Tandem Tray - Letter Fully refurbished with 90-day warranty 20L8803 Contact for Details
2000-Sheet Tandem Tray- A4	20L8802 20L8802 2000-Sheet Tandem Tray - A4 New 20L8802 (New) $1131.96 Exceeds UPS shipping dimensions / weight. Contact for Shipping Quote 20L8802 2000-Sheet Tandem Tray - A4 Fully refurbished with 90-day warranty 20L8802 Contact for Details
1500-Sheet High-Capacity Tray	20L8804 20L8804 1500-Sheet High-Capacity Tray New 20L8804 (New) $1006.18 Exceeds UPS shipping dimensions / weight. Contact for Shipping Quote 20L8804 1500-Sheet High-Capacity Tray Fully refurbished with 90-day warranty 20L8804 Contact for Details
2 x 550-Sheet Tray	20L8801 20L8801 2 x 550-Sheet Tray New 20L8801 (New) $880.41 Exceeds UPS shipping dimensions / weight. Contact for Shipping Quote 20L8801 2 x 550-Sheet Tray Fully refurbished with 90-day warranty 20L8801 Contact for Details
550-Sheet Tray	20L8800 20L8800 550-Sheet Tray New 20L8800 (New) $345.88 $308.00 20L8800 550-Sheet Tray Fully refurbished with 90-day warranty 20L8800 Contact for Details
Paper Transport	20L8817 20L8817 Paper Transport New 20L8817 (New) $188.66 20L8817 Paper Transport Fully refurbished with 90-day warranty 20L8817 Contact for Details
500-Sheet Staple Finisher	20L8810 20L8810 500-Sheet Staple Finisher New 20L8810 (New) $880.41 20L8810 500-Sheet Staple Finisher Fully refurbished with 90-day warranty 20L8810 Contact for Details
1250-Sheet Staple 2/3 Hole Punch Finisher	20L8812 20L8812 1250-Sheet Staple 2/3 Hole Punch Finisher New 20L8812 (New) $1635.06 Exceeds UPS shipping dimensions / weight. Contact for Shipping Quote 20L8812 1250-Sheet Staple 2/3 Hole Punch Finisher Fully refurbished with 90-day warranty 20L8812 Contact for Details
Folding Paper Transport	20L8811 20L8811 Folding Paper Transport New 20L8811 (New) $2138.15 20L8811 Folding Paper Transport Fully refurbished with 90-day warranty 20L8811 Contact for Details
2250-Sheet Booklet Staple 2/3 Hole  Punch Finisher	20L8814 20L8814 2250-Sheet Booklet Staple 2/3 Hole Punch Finisher New 20L8814 (New) $2955.67 Exceeds UPS shipping dimensions / weight. Contact for Shipping Quote 20L8814 2250-Sheet Booklet Staple 2/3 Hole Punch Finisher Fully refurbished with 90-day warranty 20L8814 Contact for Details
1250-Sheet Staple 2/4 Hole Punch Finisher	20L8813 20L8813 1250-Sheet Staple 2/4 Hole Punch Finisher Fully refurbished with 90-day warranty 20L8813 Contact for Details
Offset Stacker	20L8816 20L8816 Offset Stacker New 20L8816 (New) $276.70 20L8816 Offset Stacker Fully refurbished with 90-day warranty 20L8816 Contact for Details
2250-Sheet Booklet Staple 2/4 Hole Punch Finisher	20L8815
RS-232C Serial Interface Card <	14F0100 14F0100 RS-232C Serial Interface Card New 14F0100 A2379968 R4N9X (New) $98.50 14F0100 RS-232C Serial Interface Card Fully refurbished with 90-day warranty 14F0100 Contact for Details
USB Cable (2-meter)	1021294 1021294 USB (2 Meter) Cable New 1021294 (New) $18.00 1021294 USB Cable (2-meter) Fully refurbished with 90-day warranty 1021294 Contact for Details
Parallel Cable (10-foot)	1021231 1021231 Parallel Cable 25 pin D-Sub (DB-25) Male 36 pin Centronics Male 10 feet New 1021231 (New) $39.00 1021231 Parallel Cable 25 pin D-Sub (DB-25) Male 36 pin Centronics Male Fully refurbished with 90-day warranty 1021231 $29.00
Surge Protective Device, 110-120V	SPD0001 SPD0001 Surge Protective Device 110-120V New SPD0001 (New) $35.22 SPD0001 Surge Protective Device 110-120V Fully refurbished with 90-day warranty SPD0001 Contact for Details
Fax Card Option	37X6146 37X6146 MarkNet N8210 v.34 Fax Card New 37X6146 (New) Contact for Details 37X6146 MarkNet N8210 v.34 Fax Card Fully refurbished with 90-day warranty 37X6146 Contact for Details
English Keyboard Kit	57X7040 57X7040 English Keyboard Kit New 57X7040 (New) $333.43 57X7040 English Keyboard Kit Fully refurbished with 90-day warranty 57X7040 Contact for Details
Lexmark MarkNet™ N8230 Fiber Ethernet Print Server	27X0142 27X0142 MarkNet N8230 Fiber Ethernet Print Server Fully refurbished with 90-day warranty 27X0142 Contact for Details 27X0142 MarkNet N8230 Fiber Ethernet Print Server New 27X0142 (New) $547.00
Removable Hard Disk Enclosure Kit	57X0070 57X0070 External kit allowing user to remove HDD from printer setup. Kit includes: cover cables PCBA interface. New 57X0070 (New) Contact for Details 57X0070 External kit allowing user to remove HDD from printer setup. Kit includes: cover cables PCBA interface. New 57X0070 Compatible (New) Contact for Details
500GB Hard Disk Drive (SATA)	27X0420 27X0420 500GB Hard Disk Drive (SATA) New 27X0420 (New) $525.06 $469.00 27X0420 500GB Hard Disk Drive (SATA) Fully refurbished with 90-day warranty 27X0420 Contact for Details
Contactless Authentication Device	57X0301 57X0301 Contactless Authentication Device New 57X0301 (New) Contact for Details 57X0301 Contactless Authentication Device Fully refurbished with 90-day warranty 57X0301 Contact for Details
Contact Authentication Device	57X0300 57X0300 Contact Authentication Device Fully refurbished with 90-day warranty 57X0300 Contact for Details 57X0300 Contact Authentication Device New 57X0300 (New) Contact for Details
Desktop Contactless Reader	57X0225 57X0225 Desktop Contactless Reader New 57X0225 (New) Contact for Details
Contactless Front Solutions Module (Primary)	57X0235 57X0235 Contactless Front Solutions Module (Primary) New 57X0235 (New) $250.28
Bar Code License	82S1204 82S1204 Bar Code License New 82S1204 (New) $382.35
IPDS License	82S1203 82S1203 IPDS License New 82S1203 (New) $568.50
CX950 5-Year Onsite Repair NBD Warranty	2382623
CX950 4-Year Onsite Repair NBD Warranty	2382622
CX950 1-Year Renewal Onsite Repair, Response Time Next Business Day	2382625
CX950 6-Year Onsite Repair NBD Warranty	2382624
CX950 3-Year Onsite Repair NBD Warranty	2382621
CX950 Per Call On Site Repair NBD Warranty	2382630
CX950 3-Year Renewal Onsite Repair, Response Time Next Business Day	2382627
CX950 2-Year Renewal Onsite Repair, Response Time Next Business Day	2382626
CX950 1-Year Post Warranty Onsite Repair Next Business Day	2382629
CX950 4-Year Renewal Onsite Repair, Response Time Next Business Day	2382628
CX950 2-Year Onsite Repair NBD Warranty	2382620
CX950 4-Year Parts Only Extended Warranty	2382647
CX950 3-Year Parts Only Extended Warranty	2382646
CX950 6-Year Parts Only Extended Warranty	2382649
CX950 5-Year Parts Only Extended Warranty	2382648
CX950 2-Year Parts Only Extended Warranty	2382645
CX950 1-Year Parts Only Extended Warranty	2382644
CX950 2-Year Renewal Parts Only	2382651
CX950 1-Year Renewal Parts Only	2382650
CX950 4-Year Renewal Parts Only	2382653
CX950 3-Year Renewal Parts Only	2382652
Keyboard Shelf	20L8807 20L8807 Keyboard Shelf New 20L8807 (New) $88.02 20L8807 Keyboard Shelf Fully refurbished with 90-day warranty 20L8807 Contact for Details
Cabinet	20L8806 20L8806 Cabinet New 20L8806 (New) $226.40 Exceeds UPS shipping dimensions / weight. Contact for Shipping Quote 20L8806 Cabinet Fully refurbished with 90-day warranty 20L8806 Contact for Details



Our system is currently going through routine maintenance and will be available within 12 hours. We apologize for the inconvenience.

In the Box

In the Box

• Safety Information Sheet
• Setup Sheet (Network and Local Attachment)
• Software and Documentation CD
• Stability Information Sheet
• Warranty Sheet/Book (Country dependent)
• Power Cord(s)
• EMEA Contact Sheet (Country dependent)
• Up to 18,500*-page black toner cartridge
• Lexmark CS943de color laser printer
• Up to 165,000** pages black photoconductor and up to 165,000** pages CMY photoconductor
• Up to 11,500*-page cyan, magenta, yellow toner cartridges

** Photoconductor Unit and Developer Unit maximum yield estimate based on 3 average letter/A4-size pages per print job and 5% average coverage per page. Actual Yield may vary based on other factors such as device speed, paper size and feed orientation, toner coverage, tray source, percentage of black-only printing and average print job complexity.

* Average continuous black or continuous composite CMY declared cartridge yield up to this number of standard pages in accordance with ISO/IEC 19798.

Box contents may vary by country and/or reseller. Subject to change without notice.

Ethernet, USB or parallel cable not included.

---

Technical Specifications

General Specs

Part #	32D0000
Print Technology	Color Laser
Function	Color Printing Trusted Platform Module (TPM)1
Workgroup Size	Large Workgroup
Display	Lexmark e-Task 4.3-inch color touch screen
Media Sizes Supported	A6, Oficio, 7 3/4 Envelope, JIS-B4, 9 Envelope, B5, JIS-B5, A3, Ledger, A4, Legal, SRA3, A5, Hagaki Card, Letter, B5 Envelope, C4 Envelope, Statement, C5 Envelope, Executive, DL Envelope, Folio, 10 Envelope
Included Paper Handling	100-Sheet Multipurpose Feeder, 2 x 520-Sheet Tray, 400-Sheet Output Bin
Standard Ports	Gigabit Ethernet (10/100/1000), Front USB 2.0 Specification Hi-Speed Certified port (Type A), Rear USB 2.0 Specification Hi-Speed Certified Port (Type A), USB 2.0 Specification Hi-Speed Certified (Type B)
Size (in. - H x W x D)	28.1 x 24.4 x 29.3 in.
Weight (lb.)	181.9 lb.
Packaged Size (in. - H x W x D)	38.3 x 29.9 x 33.4 in.
Packaged Weight (lb.)	225.1 lb.

---

Printing

Print Speed	Up to: Black: 55 ppm2 (Letter) Color: 55 ppm2 (Letter)
Print Speed Duplex	Up to: Black: 55 spm2 (Letter)
Time to First Page	As fast as: Black: 4.9 seconds Color: 4.9 seconds
Print Resolution	Black: 1200 x 1200 dpi, 2400 IQ (2400 x 600 dpi) Color: 1200 x 1200 dpi, 2400 IQ (2400 x 600 dpi)
Duplex	2-sided: Integrated Duplex
Printable Area	0.17 inches of the top, bottom, right and left edges (within)

---

Paper Handling

Media Types Supported	Labels, Card Stock, Plain Paper, Envelopes, Glossy Paper, Refer to the Paper & Specialty Media Guide
Finishing Option	Yes
Number of Paper Inputs	Standard: 3 Maximum: 6
Paper Input Capacity	Standard: 1140 pages 20 lb or 75 gsm bond Maximum: 5140 pages 20 lb or 75 gsm bond 1140 pages 20 lb or 75 gsm bond
Paper Output Capacity	Up to: Standard: 400 pages 20 lb or 75 gsm bond Maximum: 2000 pages 20 lb or 75 gsm bond
Paper Weight Range Supported	lb.: 14 - 80 lb. (Standard Tray) 14 - 80 lb. (Multipurpose Feeder)
Finishing Functions	Offset stacking, Stapling, Hole punching, Booklet fold and saddle stapling
Optional Paper Handling	Booklet staple hole punch finisher, Inline Stapler, Dual Catch Bin, Envelope Tray, 2 x 520-Sheet Tray/Caster, Caster spacer, Tri-fold/Z-fold booklet finisher, Staple Punch Finisher, 2000-Sheet Tray, 2000-Sheet Tandem Tray/Caster
Recommended Monthly Page Volume	7000 - 50000 pages3
Maximum Monthly Duty Cycle	Up to: 270 000 pages per month4
A3 / 11 x 17	Yes

---

Cartridges & Imaging

Laser Cartridge Yields	up to: 26,0005-page Color (CMY) Cartridges 52,0005-page Black Cartridge
Photoconductor Estimated Yield	Up to: Black: 165,000 pages, based on 5 average letter/A4-size pages per print job CMY: 165,000 pages, based on 5 average letter/A4-size pages per print job
Cartridge(s) Shipping with Product	18,5005-page Black Toner Cartridge5, 11,5005-page Color (CMY) Toner Cartridges5
Replacement Cartridges:	Product functions only with replacement cartridges designed for use in a specific geographical region. See www.lexmark.com/regions for more details.

---

Hardware

Processor Speed	Quad Core 1.2 GHz
Memory	Standard: 4096 MB Maximum: 4096 MB
Hard Disk	Intelligent Storage Drive (optional); Magnetic Hard Disk (optional)
Printer Languages	Standard: PCL 5, PCLm, PCL 6 Emulation, Personal Printer Data Stream (PPDS), PostScript 3 Emulation, PDF 1.7 emulation, Direct Image
Fonts and Symbol Sets	2 PCL 5/6 bitmap fonts, 158 scalable PostScript fonts, For more information, refer to the Technical Reference., 89 scalable PCL 5/6 fonts, 5 PPDS bitmap fonts, 39 scalable PPDS fonts
Touch Screen Display	Yes

---

Connectivity

Direct USB	Yes
Ethernet Network	Yes
Network Protocol Support	IPSEC w/ IPv4, IPSEC w/ IPv6, IPv6, IPv4, ICMP, TCP, IGMP, UDP
Network Printing Methods	Pull Printing, Microsoft Web Services WSD, Enhanced IP (Port 9400), IPP 1.0, 1.1, 2.0 (Internet Printing Protocol)
Network Management Protocols	DHCP, APIPA (AutoIP), mDNS, BOOTP, WINS, DDNS, DNS, ARP
Network Security	SSL Cipher Configuration, SNMPv3, Certificate Management, TCP Restricted Server List, 802.1x Authentication: MD5, MSCHAPv2, LEAP, PEAP, TLS, TTLS, IPSEC Support (IPv4/IPv6), TCP/UDP Port Access Control, Security Port Lockdown
Optional Local Ports	Internal RS-232C serial
Optional Network Ports	MarkNet N8230 Fiber Ethernet Print Server, Marknet N8372 WiFi Option

---

Supported Operating Systems

Microsoft Windows Operating Systems Supported	Windows Server 2008 x64 running Terminal Services, Windows 11, Windows Server 2008 x64, Windows Server 2008 running Terminal Services, Windows Server 2022, Windows Server 2008, Windows 8 x64, Windows Server 2012, Windows Server 2003 x64, Windows RT, Windows Server 2003, Windows Server 2012 R2, Windows Server 2003 x64 running Terminal Services, Windows 8.1 x64, Windows Server 2003 running Terminal Services, Windows 10, Windows 8.1, Windows Server 2008 R2 running Terminal Services, Windows 8, Windows 2000 Server running Terminal Services, Windows Server 2008 R2, Windows 7 x64, Windows Server 2016, Windows XP x64, Windows Me, Windows XP, Windows Vista x64, Windows 2000, Windows Server 2019, Windows NT (4.00/4.00 Server), Windows Vista, Windows 98 2nd Edition, Windows 7
Apple Operating Systems Supported	Support is provided through AirPrint and AirScan only
Android Operating System Support	Support is provided through Mopria® Print Service and Mopria Scan.
Linux Operating Systems Supported	openSUSE Linux 15, Debian GNU/Linux 9.5, Debian 9.4, Debian GNU/Linux 9.6, Debian GNU/Linux 8.11, Ubuntu 16.04, 18.04 LTS, openSUSE Linux 42.3, Red Hat Linux 7.5, 7.6, Fedora 27, 28, 29
Citrix MetaFrame	Microsoft Windows Server 2008 R2 Standard Edition running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2003 and 2003 X64 Edition with Citrix XenApp 5.0, Microsoft Windows Server 2008 R2 Enterprise Edition running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2012 R2 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, Microsoft Windows Server 2012 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, Microsoft Windows Server 2012 Essentials running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2012 Foundation running Citrix XenApp 6.0, 6.5, Microsoft Windows Server 2008 R2 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, Microsoft Windows Server 2008 and 2008 X64 Edition with Citrix XenApp 5.0, Microsoft Windows Server 2012 Standard running Citrix XenApp 6.0, 6.5
Novell Operating Systems Supported	Novell Open Enterprise Server 2 (SP3) on SuSE Linux Enterprise Server 10 SP4 (x86 and x64) 3, Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64), Novell NetWare 6.5 Open Enterprise Server, Novell Open Enterprise Server 15 (SP1) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64), Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 12 SP1 (x86 and x64)

---

Electrical & Operation

ENERGY STAR	Yes
ENERGY STAR Typical Electricity Consumption	TEC: 0.86 kilowatt-hours per week
Noise Level	Operating: 15 dBA (Idle) 50 dBA (Print)
Duplex Print Noise Level	Operating: 52 dBA
Average Power	0.1 watts (Hibernate Mode) 1.3 watts (Sleep Mode) 76 watts (Ready Mode) 767 watts (Printing)
Specified Operating Environment	Humidity: 8 to 80% Relative Humidity Altitude: 0 - 2500 Meters (8,200 Feet) Temperature: 10 to 32°C (50 to 90°F)
Product Certifications	ENERGY STAR, ICES-003 Class A, BSMI Class A, VCCI Class A, FCC Class A, NOM-032, UL, cUL, NOM, US FDA/CDRH, IEC 60825-1, CB Report, ISO-532B, CE (EU) DoC, EFTA (CE), KC logo, CCC, C-tick DoC, EuP, CECP, CEL, EC 1275/2008, ECMA-370, TED, SII, TER, SABS, UL-AR, GS Mark, Green Dot, ISO-9296, COC, CCD-035 EcoLogo, Green Mark, EPEAT, China Green Product (CGP), Mopria Certified
UNSPSC Code	43212105
Harmonized Tariff Code	8443.32.1010
Country of Origin	Rest of World - Vietnam, North America & TAA Compliant - Mexico

---

Warranties

Limited Warranty	See Statement of Limited Warranty: 1-Year Onsite Repair, Next Business Day

---

¹The Trusted Platform Module (TPM) is not available in some countries.
²Print and copy speeds measured in accordance with ISO/IEC 24734 and ISO/IEC 24735 respectively (ESAT). For more information see: www.lexmark.com/ISOspeeds.
³"Recommended Monthly Page Volume" is a range of pages that helps customers evaluate Lexmark’s product offerings based on the average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages per month be within the stated range for optimum device performance, based on factors including: supplies replacement intervals, paper loading intervals, speed, and typical customer usage.
⁴"Maximum Monthly Duty Cycle" is defined as the maximum number of pages a device could deliver in a month using a multishift operation. This metric provides a comparison of robustness in relation to other Lexmark printers and MFPs.
⁵Average continuous cartridge yield is stated number of standard pages as listed. Declared yield value in accordance with ISO/IEC 19798.
